High Speed Axial Fan

Description

High speed axial fan

AKBZ series steel fiberglass wall-mounted high speed axial fan have the advantages of light weight, low noise, smooth operation, high efficiency, and corrosion resistance. It can be used for ventilation in machinery, chemical industry, printing and dyeing,electroplating, papermaking, food, medicine and other industries as well as theaters, hotels, offices and various residences. This series of fan impellers are developed using low-speed, high-pressure coefficient design methods, with large chord length, spatial distortion, and inclined wide blades.

Specification

No.	Air Flow (m³/h)	Pressure (pa)	Speed (r/min)	Capacity (kw)	Noise (Db(A))
2.2F	400	29	1450	0.025	54
2.5F	1000	52	1450	0.06	60
2.5T	2000	216	2900	0.37	72
2.8F	1230	45	1450	0.04	60
3.0F	1600	39	1450	0.65	62
3.2T	3000	205	2900	0.55	75
3.6F	2480	73	1450	0.09	63
4.0S	4000	98	960	0.25	63
4.0F	5000	165	1450	0.37	67
4.5F	5870	121	1450	0.25	65
5.0E	6000	79	720	0.75	63
5.0S	7000	126	960	0.55	68
5.0F	8100	162	1450	1.1	73
5.6S	7410	82	960	0.37	69
6.3E	9500	89	720	2.2	67
6.3S	12000	190	960	1.1	75
6.3F	48500	120	960	5.0	85
7.0E	15000	290	1450	2.2	79
7.0S	38000	220	720	3.0	81
7.0F	28000	290	1450	4.0	82
8.0E	25000	197	960	2.2	80
8.0S	22000	160	720	1.5	76
8.0F	25000	320	1450	3.0	80
10.0E	20000	210	960	2.2	78
10.0S	14500	140	720	1.1	72

Application

Environmental protection:High speed axial fan fan is an environmentally friendly and energy-saving fan. It has the characteristics of low investment cost, large air volume, low noise, low energy consumption, smooth operation, long service life and high efficiency.

Use with wet curtain:Used to cool down the workshop in hot summer. No matter how hot your workshop is, the wet curtain-negative pressure fan system can
reduce the temperature of your workshop to about 30C and maintain a certain humidity.

High temperature:Such as heat treatment factory, casting factory, plastic factory, aluminum profile factory, shoe factory, leather goods factory,
electroplating factory, various chemical factories.

high speed axial fan

Structure

High speed axial fans are also called local fans, which are airflows in the same direction as the axis of the blades . For example, electric fans and air conditioner outdoor fans are axial flow fans, which are commonly used in industrial . This kind of fan is different from ordinary fans. The motor and blades of a conventional axial flow fan are both in a cylinder, and the shape is a cylindrical shape.
It is used for local ventilation. It is easy to install, has obvious ventilation effect, and is safe. It can be connected to a hairdryer to send the wind to a designated area. The biggest difference between square axial flow fans and conventional axial flow fans is that the motor and blades of square axial flow fans are in a cylinder, and the shape is square, which is easier to install than cylindrical fans.

Company Profile

Shandong Aike Group is a modern enterprise integrating the design, research and development, sales and maintenance of water tank varieties, with more than ten years of supply experience. The company covers an area of 10,000 square meters and has more than 200 employees,30% of whom are excellent technical personnel. It also has a sales team that is proficient in e-commerce.

First of all, the company takes the “Belt and Road” initiative as its guide and implements its “green development” vision. Shandong Aike Group adheres to the business philosophy of “customer first, innovation-driven” and cultivates a corporate culture of “honesty and trustworthiness”.

Secondly, in recent years, its performance has continued to grow and its expansion has been steady. This trajectory has cemented lasting trust among clients and fostered lasting partnerships. In the current tide of economic development and fierce market competition, the company cherishes its hard-won honors. Shandong Aike Group unswervingly follows the road of industrialization and modernization, relies on the diligence and wisdom of “Aike” people, and unswervingly creates products with reliable quality and excellent service.

Finally, Shandong Aike Group is a leading manufacturer dedicated to providing high-quality fans to the world. Shandong Aike Group adheres to a firm commitment to pursuing excellence and specializes in the production of innovative and reliable fans, including axial flow fans, mixed flow fans, roof fans, heaters, etc.

Welcome your inquiry to us. Or leave message to us.
