Description
Mixed flow impeller fans
A fan between axial flow fans and centrifugal fans, the impeller of a mixed flow fan allows the air to move both centrifugally and axially. The movement of the air in the shell is a mixture of axial flow and centrifugal movement, so it is called “mixed flow”.
The fan mainly consists of impeller, casing, inlet collector, guide vane, motor and other parts. The impeller is welded on the hub with a twisted plate with meridian acceleration characteristics. After dynamic balance verification and overspeed test, it has good aerodynamic performance. The casing is round and connected to the air collector with silencer function as a whole. The outlet is equipped with a guide vane, which has good airflow distribution and stable pressure.
Specification
| No. | Rotational speed
(r/min) |
Operating mode
|
Volum
(m³/h) |
Total pressure
(Pa) |
Power
(Kw) |
Exit noise
dB(A) |
dB(A) | Weight
(KG) |
| 4A | 1450 | 1 | 3945 | 130.3 | 0.37 | 71 | 62 | 40 |
| 4B | 1450 | 2 | 4260 | 212.2 | 0.55 | 75 | 66 | 55 |
| 4C | 2900 | 3 | 6716 | 758.9 | 2.2 | 85 | 74 | 65 |
| 4.5A | 1450 | 4 | 4252 | 261.0 | 0.55 | 72 | 64 | 50 |
| 4.5B | 1450 | 5 | 4432 | 378.0 | 0.75 | 77 | 67 | 65 |
| 4.5C | 2900 | 3 | 8684 | 858.2 | 3 | 87 | 75 | 80 |
Application
Mixed flow impeller fans find versatile applications across various industries and environments due to their unique combination of axial and centrifugal airflow characteristics. These fans are commonly used in ventilation systems for buildings, where they efficiently move air while maintaining a relatively low noise level.
Additionally,mixed flow impeller fans are employed in cooling systems for electronics, providing effective thermal management in servers, computer cabinets, and other electronic enclosures. Their ability to deliver high airflow rates with moderate pressure makes them suitable for applications such as air conditioning units, automotive cooling systems, and industrial ventilation systems.
Overall, mixed flow impeller fans offer a balanced solution for applications that require a combination of high airflow efficiency and moderate pressure capabilities.
Company Profile
First of all, the company takes the “Belt and Road” initiative as its guide and implements its “green development” vision. Shandong Aike Group adheres to the business philosophy of “customer first, innovation-driven” and cultivates a corporate culture of “honesty and trustworthiness”.
Secondly, in recent years, its performance has continued to grow and its expansion has been steady. This trajectory has cemented lasting trust among clients and fostered lasting partnerships. In the current tide of economic development and fierce market competition, the company cherishes its hard-won honors. Shandong Aike Group unswervingly follows the road of industrialization and modernization, relies on the diligence and wisdom of “Aike” people, and unswervingly creates products with reliable quality and excellent service.
Finally, Shandong Aike Group is a leading manufacturer dedicated to providing high-quality fans to the world. Shandong Aike Group adheres to a firm commitment to pursuing excellence and specializes in the production of innovative and reliable fans, including axial flow fans, mixed flow fans, roof fans, heaters, etc.
Company project
Welcome your inquiry to us. Or leave message to us.
Email: sales@aikegroupco.com
Mixed flow impeller fans vedio
Our company could also supply the Mixed flow fan, axial roof fan blade,industrial centrifugal fans, Fire rated exhaust fan, Axial fan,4-72 centrifugal fans
